Touring / Freetouring Bindings Marker Kingpin 13 75-100 mm (7933W1MA)

Marker Kingpin 13 75-100mm Black-Red (7933W1MA) | esqui-outlet.com/en/
Marker Kingpin 13 75-100mm Black-Red (7933W1MA) | esqui-outlet.com/en/

Touring / Freetouring Bindings Marker Kingpin 13 75-100 mm (7933W1MA)

Regular price: €600.00
Reduced price: €349.99 Save €250.01
Tax included

The Marker Kingpin 13 (ref. 7933W1MA, 75–100 mm brake in Black / Red finish) is the equivalent of a front-mid-engine sports coupé with rear-wheel drive tuned for road and track: a hybrid freetouring binding that combines the lightness and natural stride of a pin toe piece on the ascent with the vertical retention, elasticity and direct power transmission of an alpine heel piece on the descent. With its carbon-reinforced ISI Toe technical toe piece, Kingpin Heel alpine heel piece, ergonomic climbing aids (0°, 7° and 13°), and DIN range from 6 to 13, it is the benchmark choice for skiers seeking agility on the ascent and millimetric precision when carving high-speed turns downhill.

ADD TO CART
Marker

Preparation time: 24h

Delivery time: 24/72h from the moment of dispatch.

Touring Ski Bindings

In the design of high-performance sports vehicles, reducing unsprung mass at the front end and reinforcing rear drive axle stiffness allows the nose to carve into a turn instantly without losing composure under heavy loads. The Marker Kingpin 13 brings this configuration to ski touring and aggressive freetouring. During the ascent, the technical ISI Toe toe piece reduces ski tip swing weight and makes stepping in easier thanks to its rubberized stop, which guides the boot inserts correctly on the first try, enabling smooth progress without mechanical resistance.

When the central switching lever is engaged in downhill mode, the binding reveals its true alpine performance: it replaces the usual touring pins with the Kingpin Heel heel piece, whose wide-base jaws press the rear boot welt toward the ski surface. This design eliminates any unwanted flex or delay in edge transitions, channeling energy directly into the skis. It features a dynamic flex compensation mechanism that absorbs ski deformation under compression, integrated titanium risers switchable with a pole (0°, 7° and 13°), a 75-100 mm brake, and official TÜV safety certification in accordance with DIN ISO 13992:2014.

Technical specifications

  • Brand and model: Marker Kingpin 13 (with pre-mounted 75-100 mm brake).

  • Manufacturer reference: 7933W1MA.

  • Sidecut: 115 - 75 - 106 mm

  • Turn radius: 11 m (149 cm), 12 m (156 cm), 13 m (163 cm), 14.5 m (170 cm), 16 m (177 cm)

  • Color / Finish: Black / Red.

  • Binding type: Hybrid Touring / Freetouring binding (Tech pin toe piece for climbing + alpine cam heel piece for descending).

  • Set weight: ~690 g per binding (~1380 g per pair with 75-100 mm brakes mounted).

  • Brake width: 75 - 100 mm (ideal for touring and freetouring skis with waist widths from 75 mm to 100 mm).

  • Release range (DIN): 6.0 - 13.0 (calibrated for advanced and expert skiers, and aggressive mountain lines).

  • Toe piece: ISI Toe with carbon fiber reinforcement, longitudinal springs and quick-entry stop.

  • Heel piece: Kingpin Heel (alpine architecture with wide jaws for direct power transmission).

  • Uphill/downhill mechanism: Manual switching lever beneath the base for safe mode changes.

  • Climbing risers: 0°, 7° and 13° positions, easily switchable with the grip or basket of a ski pole.

  • Heel longitudinal adjustment range: 25 mm of travel on the track (+/en/?controller=category 12.5 mm).

  • Height above ski (Stand Height): 21.5 mm (low center of gravity for immediate snow contact).

  • Flex compensation: Active dynamic displacement of the heel piece that follows the ski's natural flex.

  • Safety approval: Official TÜV certification in accordance with international standard DIN ISO 13992:2014 (ski touring bindings).

  • Boot compatibility: Ski touring and freetouring boots equipped with front metal Tech / Pin inserts and a standard heel welt (ISO 9523 Touring with Tech inserts).
